APC 1000VA 230V Easy UPS On-Line SRV

230,000.00

In stock

  • APC 1000VA 230V Easy UPS On-Line SRV
  • High quality, Double-conversion online UPS designed for essential power protection needs even in the most unstable power conditions.
  • Includes: Basic UPS signaling RS-232 cable, CD with software, USB cable, User manual

Output

Max Configurable Power (Watts)

800 Watts / 1.0kVA

Output Voltage Note

Configurable for 220 : 230 or 240 nominal output voltage

Efficiency at Full Load

88.0 %

Output Frequency (sync to mains)

50/60 Hz +/- 3 Hz Sync to mains

Other Output Voltages

220 V, 240 V

Load Crest Factor

3 : 1

Topology

Double conversion online

Waveform type

Sine wave

Bypass

Internal bypass (automatic and manual)

Input

Input frequency

40 – 70 Hz

Input voltage range for main operations

110 – 285 Half load, 160 – 280 Full loadV

Number of Power Cords

1

Efficiency at Full Load

88.0 %

Other Input Voltages

220 V, 240 V

Batteries & Runtime

Battery type

Lead-acid battery

Included Battery Modules

1

Typical recharge time

4hour(s)

Nominal Battery Voltage

24 V

Expected Battery Life (years)

3 – 5

Battery Charge Power (Watts)

38 Watts

Runtime APC 1000VA 230V Easy UPS On-Line SRV

Efficiency APC 1000VA 230V Easy UPS On-Line SRV

Communications & Management

Interface Port(s)

DB-9 RS-232, USB

Control panel of APC 1000VA 230V Easy UPS On-Line SRV

Multifunction LCD status and control console

Audible Alarm

Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Available SmartSlot™ Interface Quantity

1

Surge Protection and Filtering

Surge energy rating

600Joules

Physical APC 1000VA 230V Easy UPS On-Line SRV

Maximum Height

223MM, 22.3CM

Maximum Width

145MM, 14.5CM

Maximum Depth

288MM, 28.8CM

Net Weight

9.3KG

Shipping weight

10.6KG

Shipping Height

330MM, 33.0CM

Shipping Width

235MM, 23.5CM

Shipping Depth

365MM, 36.5CM

Color APC 1000VA 230V Easy UPS On-Line SRV

Black

Environmental

Operating Temperature

0 – 40 °C

Operating Relative Humidity

0 – 95 (Non-condensing) %

Operating Elevation

0 – 3000meters

Storage Temperature

-20 – 50 °C

Storage Relative Humidity

0 – 95 (Non-condensing) %

Storage Elevation

0 – 15000meters

Audible noise at 1 meter from surface of unit

50.0dBA

Online thermal dissipation

372.0BTU/hr

Protection Class

IP20

Additional information

Weight 10 kg
